Joey Aluminium is a reputable maker and supplier of Aluminium 1050 Forgings, founded proudly in Houston, USA. We offer precision-forged parts manufactured from Alloy 1050, a high-purity aluminium alloy with outstanding corrosion resistance, superb electrical and thermal conductivity, and outstanding formability. Aluminium 1050 is a non-heat-treatable alloy well suited for applications that involve low stresses and demand lightweight, corrosion-resistant components. Our 1050 forgings come in custom sizes, shapes, and tempers, manufactured to ASTM B247 and international forging specifications. Joey Aluminium provides high-quality manufacturing, precise tolerances, and prompt delivery to the USA and global markets.
Aluminium 1050 Forgings have a minimum of 99.5% aluminium with minor traces of iron (≤0.4%), silicon (≤0.25%), and trace elements such as copper, manganese, and zinc. These forgings have mechanical properties of tensile strength from 60–100 MPa and yield strength from 20–85 MPa, depending on the temper (O, H14, etc.). The trade name “Aluminium 1050 Forgings” is given to aluminium parts formed by compressive forces for use in applications where formability, corrosion resistance, and conductivity are utmost priority.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Joey Aluminium based in Houston , USA is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Joey Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@joeyaluminium.us
Aluminium 1050 Forgings are extensively applied in the electrical industry for pieces such as terminals, connectors, and busbars because of their superior electrical conductivity. They are suitable for low-load structural components and non-reactive equipment like valves, flanges, and fittings in the food and chemical processing industries. In architectural and design applications, they are employed for bespoke forged shapes requiring corrosion protection and a polished finish. These forgings are also utilized in thermal and reflective systems, lightweight mechanical components, and marine applications. Aluminium 1050 Forgings have purity coupled with workability and are well-suited for a vast range of custom-designed, low-stress components.
