Joey Aluminium is a reliable producer and supplier of **Aluminium 2024 Channels** with headquarters in Houston, USA. We offer precision-engineered aluminium channels produced from Alloy 2024, an airframe alloy of high strength, heat treatable, and which is chiefly used in aerospace as well as structural applications. With remarkable fatigue resistance and large strength-to-weight ratio, Aluminium 2024 is perfect for load-carrying parts in harsh environments. Our Aluminium 2024 channels come in various sizes and tempers (e.g., T3 and T351) and are of international quality standards. With stable production facilities and timely delivery, Joey Aluminium provides Aluminium 2024 structural profiles to industries around the USA and the world.
Aluminium 2024 Channels consist primarily of aluminium (~90.7%), copper (3.8–4.9%), with other elements such as magnesium (1.2–1.8%), manganese (0.3–0.9%), and minor traces of iron, silicon, and chromium. These sections provide good mechanical properties, tensile strength 400–500 MPa and yield strength 250–450 MPa based on temper. Product name “Aluminium 2024 Channel” specifies a U- or C-shaped general-purpose structural section employed in the framing, bracing, and reinforcement of structures where strength and weight efficiency are paramount.
Specifications: ASTM B211 / ASME SB211
Temper: O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Thickness: 0.91mm to 10 mm
Length: 10 to 12 Feet or as per clients’ requirement
Width: 9.5 mm X 9.5 mm To 150 mm X 75 mm or Custom
Finish: Mill, Customer specific finish
Surface: Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
Form: C-Channel, Box-Channel, U-Channel, J-Channel, Hat Channel, Strut Channels, Miscellaneous Channels
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
Joey Aluminium based in Houston , USA is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
Yes, we offer custom sizes for Aluminium 2024 Channel to meet specific project needs. Our team at Joey Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@joeyaluminium.us
