Joey Aluminium is a leading manufacturer and supplier of high-quality aluminium products based in Houston , USA. Specializing in the production of Aluminium 7075 flanges, the company is renowned for delivering precision-engineered solutions to meet diverse industrial needs. With a commitment to excellence, Joey Aluminium provides robust, corrosion-resistant, and lightweight aluminium products designed for optimal performance in demanding applications. Their dedication to quality, reliability, and customer satisfaction makes them a trusted partner in the aluminium manufacturing industry.
Joey Aluminium, located in Houston, USA, stands out as a top manufacturer and supplier of high-performance Aluminium 7075 Flanges. We pride ourselves on delivering precision-engineered solutions to industries that require exceptional strength and reliability. Renowned for our premium-grade aluminium products, we create 7075 flanges that meet the stringent standards of aerospace, defense, marine, and industrial applications. Our flanges are meticulously crafted using advanced manufacturing techniques and rigorous quality control, ensuring remarkable mechanical performance, precise dimensions, and long-lasting durability. With a focus on customer satisfaction and quick delivery, we cater to clients across the USA with Aluminium 7075 Flanges designed for critical operations.
Standards : ASTM B247 / B/SB 247
Temper : H14
Thickness : 1 Mm To 100 mm
Diameter : Upto 2000 mm
Flange Diameter : 3″ DIA up to 38″ DIA 1500 lbs max
Flanges Form : Hot Rolled Flanges, Cold Rolled Flange, Proof Machined Flanges
Finish :Mill, Customer specific finish
Aluminum Flange Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
Our Aluminium 7075 Flanges are made from a high-strength aluminium-zinc alloy that contains 5.6–6.1% zinc, 2.1–2.5% magnesium, 1.2–1.6% copper, and trace amounts of chromium. This heat-treatable alloy boasts one of the highest strength levels among commercial aluminium grades. In tempers like T6 and T651, it achieves tensile strength exceeding 500 MPa, along with excellent fatigue resistance and good machinability. While its corrosion resistance is moderate, it can be enhanced through anodizing or surface treatments.
Yes, we offer custom sizes for Aluminium 7075 Flanges to meet specific project needs. Our team at Joey Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@joeyaluminium.us
Aluminium 7075 Flanges find their place in applications that demand lightweight materials with high structural integrity under extreme stress. These include aerospace assemblies, defense systems, motorsport vehicles, pressure vessels, high-performance machinery, and marine components. Their strength and dimensional stability make them perfect for high-load and precision-fit flange connections in piping and structural frameworks. At Joey Aluminium, we offer Aluminium 7075 Flanges in various types—including weld neck, slip-on, and blind flanges—customized to meet the exact specifications of demanding industries throughout the USA.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
