Joey Aluminium, a respectable producer and supplier of premium Aluminium 1050 Chequered Plates with headquarters in Houston, USA, offers reliable and affordable solutions for a range of architectural and industrial applications. These plates are made to exacting industry standards and are renowned for their outstanding workability, resistance to corrosion, and bright finish. Joey Aluminium provides specialised sizes and fast delivery services to industries like interior design, construction, and transportation. Joey Aluminium is still a reliable supplier of aluminium chequered plates in both domestic and foreign markets thanks to its strong emphasis on quality, innovation, and customer satisfaction.
99.5% pure aluminium makes up the composition of Aluminium 1050 Chequered Plates, with trace amounts of silicon, copper, iron, and other elements. Superior formability, exceptional thermal and electrical conductivity, and exceptional corrosion resistance are all provided by this high-purity alloy. The plates are perfect for bending and shaping because of their high elongation values up to 35%, yield strength of about 30 MPa, and tensile strength of roughly 60–100 MPa. 1050 is a popular option for decorative and light-duty structural applications because it provides exceptional surface finish and workability, despite not being as strong as alloyed aluminium grades.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24
Thickness : 0.2-50
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Joey Aluminium based in Houston , USA is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Chequered Plates to meet specific project needs. Our team at Joey Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@joeyaluminium.us
Applications needing materials that are lightweight, corrosion-resistant, and aesthetically pleasing frequently use aluminium 1050 Chequered Plates. Because of their attractive surface and reflectivity, they are frequently used in architectural design for ceiling panels, flooring, and wall cladding. They are utilised in luggage compartments, bus and train flooring, and automobile interiors. These plates are also appropriate for non-slip surfaces, protective coverings, and signage in both residential and commercial buildings. They are perfect for settings that value both appearance and functionality because of their exceptional formability and anti-slip qualities, particularly when low-to-moderate strength requirements are present.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
