Reputable Houston, USA-based Joey Aluminium is a manufacturer and supplier of Aluminium 5083 Chequered Plates, which are known for their exceptional strength, resistance to corrosion, and non-slip surface. These plates are perfect for transportation, offshore, marine, and structural applications because they are designed to function in the most demanding conditions. Joey Aluminium guarantees that every product satisfies global quality standards while providing customised sizes and finishes to satisfy client demands. Supported by cutting-edge production methods and an emphasis on accuracy, the business provides clients in the United States and overseas with trustworthy aluminium solutions and first-rate customer support.
The primary component of Aluminium 5083 Chequered Plates is aluminium (92–95%), with minor additions of manganese (0.4–1.0%) and chromium (0.05–0.25%) and substantial amounts of magnesium (4.0–4.9%). Excellent corrosion resistance is offered by this composition, particularly in industrial and marine settings. The plates have good elongation (≥10%), a high tensile strength of about 275–350 MPa, and a yield strength of about 200–280 MPa. They are renowned for their outstanding performance under stress, moderate formability, and excellent weldability. The chequered surface adds anti-slip properties, making them suitable for both structural and safety-oriented applications.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38,H111,H112,H114,H116,H321
Thickness : 0.5-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5Mn0,7 | AG4,5MC | 3.3547 | A95083 | AlMg4,5Mn0,7 | 5083 | AlMg4,5Mn |
| Al | Si | Fe | Cu | Mn | Cr | Mg | Ti | Zn | Other Each | Others Total |
| Bal | 0.40 max | 0.40 max | 0.10 max | 0.40 / 1.0 | 0.05 / 0.25 | 4.0 / 4.90 | 0.15 max | 0.25 max | 0.05 max | 0.15 max |
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
Joey Aluminium based in Houston , USA is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5083 Chequered Plates to meet specific project needs. Our team at Joey Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@joeyaluminium.us
Applications requiring high strength, resistance to corrosion, and non-slip surfaces frequently use aluminium 5083 Chequered Plates. Because they don’t corrode in saltwater, they are perfect for shipbuilding, decking, and hull plating in the maritime sector. They are utilised in loading ramps, trailers and truck beds in the transportation industry. They are also used in industrial flooring, walkways, stairways, and oil and gas platforms. They are a great option for structural and safety elements in both onshore and offshore settings because of their exceptional durability, lightweight nature, and non-slip texture.
